Simple & Hygiene Door System!
Watch the video now!
Simple & Hygiene Door System!
Watch the video now!
We have 2 types of
Sliding Door Systems
SD Motor Drive
Automatic Sliding Door
Advantages :
• For Commercial Area
• Rail Up to 6 Meter per Track
• Rail can cut to any size to match your door width
• Most Suitable for Double Door Sliding Door
SDM Magnetic Drive
Automatic Sliding Door
Advantages :
• For private area : Kitchen, Bathroom, Office etc
• Door rail float on track by magnet force
• Super Quiet Operation
• Rail is Super Slim, looks better in indoors.
• Normal For Single Leaf Sliding Door
We have 2 types of
Sliding Door Systems
SD Motor Drive
Automatic Sliding Door
Advantages :
• For Commercial Area
• Rail Up to 6 Meter per Track
• Rail can cut to any size to match your door width
• Most Suitable for Double Door Sliding Door
• Rail Up to 6 Meter per Track
• Rail can cut to any size to match your door width
• Most Suitable for Double Door Sliding Door
SDM Magnetic Drive
Automatic Sliding Door
Advantages :
• For private area : Kitchen, Bathroom, Office etc
• Door rail float on track by magnet force
• Super Quiet Operation
• Rail is Super Slim, looks better in indoors.
• Normal For Single Leaf Sliding Door
• Door rail float on track by magnet force
• Super Quiet Operation
• Rail is Super Slim, looks better in indoors.
• Normal For Single Leaf Sliding Door
Safety Beam Sensor
A Safety Beam Infrared Detector will sense any obstacle in the path, stop the door from closing.
Safety Beam Sensor
A Safety Beam Infrared Detector will sense any obstacle in the path, stop the door from closing.
4 Door Open Mode
There are 4 Door Open Mode: Always Open, Always Close, Auto Half Open and Auto Full Open Mode.
1. Always Open
Open all the time
2. Always Close
Close all the time
3. Auto Half Open
When trigger open halfway
4. Auto Full Open Mode
When trigger fully open
4 Door Open Mode
There are 4 Door Open Mode: Always Open, Always Close, Auto Half Open and Auto Full Open Mode.
1. Always Open
Open all the time
2. Always Close
Close all the time
3. Auto Half Open
When trigger open halfway
4. Auto Full Open Mode
When trigger fully open
Door Access Mode
For your convenience, you can set up to 3 access mode. Anything that suits you the best!
A. Automatic Open Close
• Double side Microwave Sensor
B. Touch to Open
• Wired Push Button
• Wireless Push Button
C. Restriction Area Access
• One Side microwave Sensor
• One Side Door Access Device
Door Access Mode
For your convenience, you can set up to 3 access mode. Anything that suits you the best!
A. Automatic Open Close
• Double side Microwave Sensor
B. Touch to Open
• Wired Push Button
• Wireless Push Button
C. Restriction Area Access
• One Side microwave Sensor
• One Side Door Access Device
Support Devices :
Microwave Sensor
Push Button
Wireless Wave Button
Door Access Panel
Face Access Terminal with
Temperature Screening
Support Devices :
Microwave Sensor
Push Button
Wireless Wave Button
Door Access Panel
Face Access Terminal with
Temperature Screening
Technical Data :
Click Measurement Diagram To Enlarge
SD-125 Automatic Sliding Door Operator
Drive Unit :
Motor Drive
Door Type :
Single door / Double door
Door Weight :
Single Door 1 X 150kg, Double Door 1 X 125kg
Door width :
750-1600mm / 650-1250mm
Power supply :
AC240V, 50/60Hz
Power consumption :
8W (idle), 65W (Working)
Opening speed :
Adjustable 150-460mm/s
Closing speed :
Adjustable 130-460mm/s
Door Open time :
Adjustable 0-8s
Manual force :
Single Door 40N, Double Door 50N
Temperature range :
-20 ~ +50℃
Rail length :
2100mm, 4200mm, 6000mm
Technical Data :
Click Measurement Diagram To Enlarge
SD-125 Automatic Sliding Door Operator
Drive Unit :
Motor Drive
Door Type :
Single door / Double door
Door Weight :
Single Door 1 X 150kg, Double Door 1 X 125kg
Door width :
750-1600mm / 650-1250mm
Power supply :
AC240V, 50/60Hz
Power consumption :
8W (idle), 65W (Working)
Opening speed :
Adjustable 150-460mm/s
Closing speed :
Adjustable 130-460mm/s
Door Open
time :
time :
Adjustable 0-8s
Manual force :
Single Door 40N, Double Door 50N
Temperature range :
-20 ~ +50℃
Rail length :
2100mm, 4200mm, 6000mm
SDM Maglev Ultra Silent Automatic Sliding Door Operator
Door configuration :
Single door / Double door (Need 2 set)
Door weight :
Max 100kg
Max door width :
M090 (90cm), M100 (100cm), M110 (110cm)
Rail length :
M090 (190cm), M100 (210cm), M110 (230cm)
Power voltage :
AC240V, 50/60Hz
Power consumption :
3W (idle), 80W (Working)
Opening speed :
Adjustable 150-500mm/s
Closing speed :
Adjustable 150-500mm/s
Door Open time :
Adjustable 0-20s
Working temperature :
-20 ~ +50℃
SDM Maglev Ultra Silent
Automatic Sliding Door Operator
Door configuration :
Single door / Double door (Need 2 set)
Door weight :
Max 100kg
Max door
width :
width :
M090 (90cm), M100 (100cm), M110 (110cm)
Rail length :
M090 (190cm), M100 (210cm), M110 (230cm)
Power voltage :
AC240V, 50/60Hz
Power consumption :
3W (idle), 80W (Working)
Opening speed :
Adjustable 150-500mm/s
Closing speed :
Adjustable 150-500mm/s
Door Open
time :
time :
Adjustable 0-20s
Working temperature :
-20 ~ +50℃
Installation Gallery
Installation Gallery
Here are another 2 types of
Common Auto Door
Automatic Swing Door Operator
Automatic Floor Spring Door
Here are another 2 types of
Common Auto Door
Automatic Swing Door Operator
